Field

Overview

Field folds the web family’s Field/FieldLabel/FieldControl/FieldDescription/FieldItem/FieldError/ FieldValidity/Input anatomy into one push-based coordinator. Instead of cascading a FieldContext object for descendants to pull (WPF has no cascading-parameter mechanism), NaviusField walks its logical tree once its Content is assigned, registers the descendant control (default-filling an empty NaviusFieldControl with a NaviusInput), wires the label’s Target, and pushes fresh validity into every NaviusFieldError. The web’s discrete state attributes become read-only dependency properties computed from WPF’s own bubbling Validation.Error, TextChanged, and GotFocus/LostFocus events instead of a ported JS constraint-validation bridge.

Usage

xmlns:field="clr-namespace:Navius.Wpf.Primitives.Controls.Field;assembly=Navius.Wpf.Primitives"

<field:NaviusField FieldName="email" ValidationMode="OnBlur">
    <StackPanel>
        <field:NaviusFieldLabel Content="Email" />
        <field:NaviusFieldControl>
            <field:NaviusInput Text="{Binding Email, ValidatesOnNotifyDataErrors=True}" />
        </field:NaviusFieldControl>
        <field:NaviusFieldDescription Content="We only use this to send receipts." />
        <field:NaviusFieldError />
    </StackPanel>
</field:NaviusField>

Properties

Property	Type	Default	From	Description
FieldName	string	""	NaviusField	Form-field name key, matched against NaviusForm.Errors. Renamed from the web’s Name to avoid hiding FrameworkElement.Name, which x:Name/FindName rely on.
Disabled	bool	false	NaviusField	Drives IsEnabled; combined with an enclosing NaviusFieldset’s own disabled cascade via native IsEnabled tree inheritance.
Invalid	bool	false	NaviusField	Consumer “mark invalid” flag. Does not auto-clear.
ServerInvalid	bool	false	NaviusField	Server-side invalidity. Auto-clears on the next descendant TextChanged.
ValidationMode	FieldValidationMode	OnSubmit	NaviusField	OnSubmit / OnBlur / OnChange; gates when IsFieldValid/IsFieldInvalid are revealed.
ExternalErrors	IReadOnlyList<string>?	null	NaviusField	Error messages injected by name, typically by NaviusForm.Errors.
IsFieldValid	bool?	null	NaviusField	Read-only. Tri-state: null until Reveal()’d, matching the web’s valid: null.
IsFieldInvalid	bool	false	NaviusField	Read-only.
IsDirty	bool	false	NaviusField	Read-only. Set on the first descendant TextChanged.
IsTouched	bool	false	NaviusField	Read-only. Set on the first descendant LostFocus.
IsFilled	bool	false	NaviusField	Read-only. True when the registered TextBox’s Text is non-empty.
IsFieldFocused	bool	false	NaviusField	Read-only. Tracks descendant GotFocus/LostFocus.
RegisteredControl	UIElement?	null	NaviusField	CLR property (not a DP): the descendant control found or default-filled by WireDescendants.
Content	object	-	ContentControl (NaviusFieldControl)	Hosts the field-aware control; NaviusField default-fills a NaviusInput when left empty and registers whatever ends up here.
Target	FrameworkElement	null	Label (NaviusFieldLabel)	Wired by the ancestor NaviusField to the registered control; gives native Alt+mnemonic focus, plus an explicit PreviewMouseLeftButtonDown handler for plain-click delegation (WPF’s Label does not focus Target on a non-mnemonic click by itself).
Content	object	-	ContentControl (NaviusFieldDescription)	Supplementary field text; NaviusField reads its string Content and applies it as AutomationProperties.HelpText on the registered control.
Content	object	-	ContentControl (NaviusFieldItem)	Groups one item’s label + description (e.g. inside a checkbox/radio list); no field-state wiring of its own.
Match	string?	null	NaviusFieldError	Narrows display to a specific error message string (not an HTML5 validity key); null shows whenever the field is invalid.
ForceMatch	bool	false	NaviusFieldError	Shows unconditionally regardless of validity.
Content	object	null	ContentControl (NaviusFieldError)	Custom error content; when null and shown, defaults to the joined error messages.
Text	string	""	TextBox (NaviusInput)	Inherited from TextBox; natively two-way bindable, no separate Value/DefaultValue pair is needed.

Methods

Method	Description
Reveal()	Surfaces current validity per ValidationMode. Called by NaviusForm on every submit attempt (the stand-in for the web’s FieldContext.RevealAsync()); a consumer can also call it directly outside a Form.
RegisterControl(UIElement)	Registers an arbitrary descendant as the field’s control (used internally by WireDescendants).
FocusRegisteredControl()	Focuses RegisteredControl; called by NaviusForm to focus the first invalid field.

UIA mechanism

NaviusField ships no custom AutomationPeer. Accessible-name association happens on the registered control, not the field wrapper: NaviusFieldLabel.Target gives native Label→control wiring, and AutomationProperties.HelpText is applied to the registered control from the first NaviusFieldDescription descendant’s string content (fixed in the M6 audit; previously missing entirely). NaviusFieldError carries AutomationProperties.LiveSetting=Assertive, the UIA analog of role="alert". The discrete state DPs (IsDirty/IsTouched/IsFilled/IsFieldFocused/ IsFieldValid/IsFieldInvalid) are computed from real bubbling WPF events rather than surfaced attributes. The unit suite exercises this against real windows, including the M6 regression FieldTests.FieldDescription_IsAssociatedWithControl_ViaAutomationHelpText.

Web deltas

• No cascading-parameter equivalent exists in WPF: NaviusField pushes to descendants on OnContentChanged instead of parts pulling a cascaded FieldContext, deliberately avoiding FrameworkElement.Loaded, which never fires outside a live Window.
• The web’s GUID id registry (ControlId, DescribedBy, message ordering) is dropped entirely: label/description association uses element references (Label.Target, AutomationProperties.HelpText) instead of for=/aria-describedby ids.
• FieldValidity’s HTML5 ValidityState flag set (BadInput/PatternMismatch/StepMismatch/…) collapses to a single invalid/valid plus message-list model read off WPF’s own Validation.GetErrors, so NaviusFieldError.Match matches a message string, not a validity key.
• Name became FieldName (FrameworkElement.Name is load-bearing for x:Name/FindName).
• ServerInvalid auto-clears only on a descendant TextChanged: what counts as “the next edit” for non-text controls (ComboBox, DatePicker, CheckBox) stays unresolved, the same open question the web contract itself leaves open.
• The ControlProps/@attributes splat pattern (NaviusFieldControl.ChildContent cascading a custom control’s wiring) is replaced by WPF’s ordinary Content model: any control placed inside NaviusFieldControl gets registered, nothing needs to be splatted.
• NaviusFieldValidity (a render-prop exposing the live validity snapshot) has no separate control: consumers bind directly to the public read-only DPs instead.
• Known residual (M6 audit): the label-to-control accessible-name relationship relies solely on native Label.Target, not an explicit AutomationProperties.LabeledBy the way NaviusFieldset wires it for its legend; this was not independently verified with a screen reader or UIA client.
• Known residual (M6 audit): the error message is surfaced only as an assertive live region, not also mirrored into the control’s HelpText, so a screen reader that reads describedby/help on focus rather than the live announcement would not hear the current error. Parity of announcement with the web’s aria-describedby error ids was not verified with assistive technology.

Captures

The Field Gallery page rendered at the pinned commit, in each theme.
